Kompressor

type: rotary twin screw, single-stage, oil-cooled

free air delivery m3/ min : 5.2

rated opera ng pressure kg/ cm2 ( PSIG) ( kPa) : 7( 100) ( 690)

receiver tank capacity m3 ( US gal) : 0.02( 5.3)

air outlets : 20A( 3/4" ) x2pcs

engine make/ model : ISUZU / NISSAN

type : 4 cycle water cooled direct injec on type

no.of cylinder : 4

total displacement cc : 2, 189

rated output PS ( kW) / rpm : 49.5( 36.4) / 3, 000

fuel tank capacity liters ( US gal) : 90( 23.8)

Lubrican oil capacity liters ( US gal) : 7.4( 2.0)

dimension & weight :

overall length mm : 2, 960

overall width mm : 1, 650

overall height mm : 1, 510

weight ( dry) kg( lb) : 860( 2, 116)

weight ( wet) kg( lb) : 960( 2, 116)

Tire size : 175r13 8prx2w
